Onex 102

Share on:

Features (Low Position Type)

Besides Onex 102 (Standard Position Type), Onex 102 (Low Position Type) is also available as an option. The minimum height of this type is only 550mm.



  • Special design of low position
  • 4-section design to meet different requirements of surgical positions
  • Acentric structure with T-shape base. Convenient for using X-ray and C-arm (head and leg plates NOT interchangeable)
  • Stable hydraulic system with square column, high load-bearing and low movement noise
  • Stainless steel body structure with detachable polyurethane pads, antipollution, anticorrosive and moisture-proof
  • Wire handset control with touch keypad, safety lock in 30 seconds to prevent faulty operation, optional for backup battery supply
  • Fast and solid assembling and disassembling with high quality pneumatic spring
Category: .

Brand: .

Product Description

Technical data Sternmed

Onex 102 (standard position type)

Onex 102 (low position type)

Control of Position

Electro hydraulic with a wire handset

Max. Table Length (Inc. Head Plate & Leg Plates)

2050mm

2050mm

Max. Table Width (Back Plate Only)

480mm

480mm

Lowest Table Level

690mm

550mm

Highest Table Level

1040mm

800mm

Lifting Distance

350mm

250mm

Forward/Backward Leaning Angle

>20°/>15°

>20°/>15°

Left/Right Leaning Angle

>15°/>15°

>15°/>15°

Max. Height of Cone

>110mm

>110mm

Upward/Downward for Back Plate

>75°/>12°

>75°/>12°

Upward/Downward for Head Plate

>90°/>90°

>90°/>90°

Upward/Downward/Outward for Leg Plates

>10°/>90°/>90°

>10°/>90°/>55°

Load Capacity

200kg

200kg

Power Supply

A.C. 220V+10%/50+1Hz

Input Power

<650VA
